Notebook: Feb 2026
🤖 Motion Controller ESP32
[DONE] new stepper driver TMC2130 x4 install + test
[DONE] real time motor manual control
[WIP] movie mode (reset, save, delete)
🎥 Sony RX0II
Redesign lens mount to accept different flange distance, short for close focus (TTV), standard for normal FOV (car mount / tight space)
[WIP] close focus
[WIP] normal focus
🎥 Sony A7RII anamorphic
[DONE] setup for vertical mount
Note: Body in vertical + 2x anamorphic = 4:3 ratio master.
Taking Lens: Biotar 58mm/2
Anamorphic Scope: Schneider Cinelux 2x
Single Focus: Rapido FVD-16A
By shooting S35 Portrait with a 58mm 2x lens:
Landscape shot feels like a: 41.5mm
Portrait shot feels like a: 131mm
De-squeezed Source (Camera in Portrait)
Sensor Orientation: 15.6mm (W) x 23.5mm (H)
De-squeezed Area: 31.2mm (W) x 23.5mm (H)
Aspect Ratio: 4:3
Landscape Crop (16:9)
Width Used: 31.2mm
Height Used: 17.5mm
Equivalent Horizontal FOV: 41.5mm
Equivalent Vertical FOV: 73.8mm
Portrait Crop (9:16)
Width Used: 13.2mm
Height Used: 23.5mm
Equivalent Horizontal FOV: 131mm
Equivalent Vertical FOV: 58mm
🚘 GC8 WRX
[WIP] ECU remap
ProjectLambda - log to build VE table (speed density)
[DONE] limiter: boost limit
Tight Control: If a vacuum hose pops off from the solenoid, the wastegate will stay shut and boost will skyrocket. With the limit at 220 kPa, the ECU will cut fuel/ignition immediately to save the motor.
Altitude Protection: As it go higher (lower atmospheric kPa), the turbo has to spin much faster to reach the same pressure. Lowering the limit at altitude protects the turbo from overspeeding.
[DONE] boost control:
Boost Target - Intake Air Temperature Compensation
Wastegate Max - Intake Air Temperature Compensation
Wastegate Max - Atmospheric Pressure Compensation
Wastegate Duty Cycle - Base
Wastegate Duty Cycle - Max
Wastegate Duty Cycle - Overboost Step
Wastegate Duty Cycle - Underboost Step
Wastegate Duty Cycle - Overboost Step (Transition)
Wastegate Duty Cycle - Underboot Step (Transition)
Boost Control - Wastegate Duty Integral Limit
Waste Output Frequency (25Hz for Apexi 3-port solenoid)
Safety Note: Set Boost Cut (Fuel Cut) to 220 kPa (approx 1.15 bar) to catch overboost spikes without being dangerously close to the limit.
If it ain’t hitting the 201 kPa target during a 3rd gear pull, increase the values in the 100.0 TPS column by 2% at a time.
Hardware Note: MY08 STI TMIC installed. BOV deleted. Watch for compressor surge on lift-off. Larger core volume may require slightly higher WGDC to hit 1.0 bar target compared to stock core.
